1.Products Introduction of Flat Pack Office Container House With Double Slopes Roof
In many countries around the world, our clients are looking for a flat pack office container house with double slopes roof. The settings of Akay container house slope roof can be adjusted according to actual condition, including location, double or single slope slope roof. The top of flat pack office container house only need to match with sandwich panel to close, add a slope roof, not only solved the problems of waterproof, and realize the beautiful appearance, The combination container office has been well received.
2.Products Parameter (Specification) of Flat Pack Office Container House With Double Slopes Roof
|
Name |
Flat Pack Container House With Double Slopes Roof |
|
Sizes |
Outside size:5960mm*3010mm*2810mm（customized) Outside size:5960mm*6020mm*2810mm（two-in-one) |
|
Inside size：5735mm*2800mm*2500mm（customized) |
|
|
Base |
Long beam:5760mm*(2.0-3.0mm)*2pcs, hot rolled galvanized steel |
|
Short beam:2810mm*(2.0-3.0mm)*2pcs, hot rolled galvanized steel |
|
|
Column:2470mm*(2.0-3.0mm)*4pcs, hot rolled galvanized steel. |
|
|
Corner Fitting:4.5-5.0mm*4pcs |
|
|
Square steel purlin:2880*80*80*(1.6-1.7mm)*4pcs，2880*80*40*(1.6-1.7mm)*5pcs |
|
|
Roof |
Long beam:5760mm*(2.0-3.0mm)*2pcs, hot rolled galvanized steel |
|
Short beam:2810mm*(2.0-3.0mm)*2pcs, hot rolled galvanized steel |
|
|
Corner Fitting:4.5-5.0mm*4pcs, hot rolled galvanized steel |
|
|
Pressure steel channel:5730*183*2pcs，2780*183*2pcs |
|
|
Angle steel:5730*30*30*2pcs |
|
|
T-shaped steel for roof:1883*78*(1.0-1.2mm)*6pcs |
|
|
C-style steel:1883*80*35**(1.0-1.2mm)*3pcs |
|
|
Square steel:5735*40*40*(1.0-1.2mm)*1pc，2785*80*40*(1.0-1.2mm)*2pcs |
|
|
Water tank:5840*280*2pcs |
|
|
Roof decoration |
Roofing Sheet:2900mm*980*7pcs，2770mm*831*7pcs |
|
Other material:glass wool |
|
|
Wall |
Size:50mm EPS sandwich panel/Rock wool sandwich panel |
|
Color:white or other optional colors |
|
|
Steel sheet:0.286/0.326/0.376/0.426/0.476mm |
|
|
Door |
2035mm*925mm Zinc iron alloy door with lock or optional door |
|
Window |
1100mm*950mm*2pcs Plastic-steel window or optional window |
|
Floor |
MGO floor or cement fiber floor |
|
Total weight |
About 1300kg |
|
Other material |
Hardware,Water pipe,Wrap angle,Decorative strips,silicon sealant etc. |
The above is the configuration list of a standard container house. We will install your requirements to develop the flat pack container office plan and materials, please contact us now.
3.Product Feature And Application of Flat Pack Office Container House With Double Slopes Roof
The features of flat pack container house:
1. It can be anti-earthquake typhoon, waterproof and fire prevention.
2. It can heat insulation, durable, long service life.
3. It can be fast and easy to install, simple installation tools can be quickly assembled, no crane and other mechanical equipment.
4. It can be installed in the outdoor anywhere you need, which can be stacked up to 3 floors, with double sloping roof on the top floor, outdoor recreation cabin, farm yard, outdoor guardhouse, long-term living room, etc.
Our flat pack container house with double slopes roof adopts hot-rolled galvanized steel after spraying and high-temperature baking can be used for a long time.Its stability and stress resistance ensure a service life of more than 20 years, choosing flat pack container house with double slopes roof can save housing costs and construction time.
4.Product Details of Flat Pack Office Container House With Double Slopes Roof
For the quality assurance of flat pack container house with double slopes roof, We control the whole process of production and pay attention to detail management.The production process is up to standard,adhere to ensure the quality of products by using high-quality materials.
5.Product Qualification of Flat Pack Office Container House With Double Slopes Roof
Because of the stability and wide application of flat pack container house with double slopes roof. Akay flat pack container houses have spread all over most cities in China, and are exported to Asia, America, Europe and other regions.Our whole series flat pack office container house are in conformity with CE certification standards and in accordance with ISO system standards for management and production.
6. Deliver,Shipping And Serving of Flat Pack Office Container House With Double Slopes Roof
We have enough excellent equipment and teams to achieve large-scale production of flat pack office container house with double slopes roof.Our production efficiency guarantee can be delivered within 3 days at the soonest, the delivery time depends on your order quantity.
Type of shipping: container shipment,EX works or other options.
Our service:the dimensions of flat pack office container house with double slopes roof, the thickness of the steel structure and sandwich panel, and the color of the container house can all be customized according to your needs. We provide installation videos and instructions to facilitate on-site installation.
7.FAQ
Q1:Are you a factory or a trading company?
A1:We are a professional manufacturer of flat pack container houses with 10 years of R&D and production experience,we are a cooperative factory of numerous Chinese exporters of flat pack container offices and detachable container houses.
Q2:What kind of prefabricated housing do you offer?
A2:Detachable container house,flat pack container house,prefabricated T homes and prefabricated K homes,portable sandwich panel toilet and portable security house and so on.
Q3:What information should we offer before you quote?
A3. If you have drawings, please send them to us and tell us the specifications and thicknesses of the materials you use, etc.
If you don't have the drawings, please tell me all your detailed requirements, including the size of the house, the purpose, the number of doors, Windows, stairs, etc., and the installation position, then we will design an ideal house for you.
Q4:How long is your fastest delivery time?
A4: Our fastest delivery time is within 3 days. If it is a bulk order, the time will be extended accordingly, and we will do our best.
